Marine Universal GPS Receiver Boat Yacht Antenna RS232 Serial NMEA0183 4800

Marine Active GPS Antenna & Receiver 5M cable

   9v-28v supply with RS232 data output

   Perfect for 12v or 24v supplies

   Supplied with mounting base.

** Shipped 1st Class - Items dispatched twice daily :-) **

Suitable for all Marine equipment which requires

   a GPS Antenna / receiver which uses RS232 Serial data

   Use industry standard NMEA0183 data message format

   Ideal for OPENCPN and other software

  default Baud rate is 4800 but this can be changed 4800-921600

   default update rate is 1Hz but this can be changed 1Hz-10Hz

   Settings can be saved in Flash

Images are for illustration purposes, model may vary

Also suitable for industrial / vehicle or other applications

   which require an outdoor waterproof GPS antenna.

Suitable for use with OPENCPN - Windows 7 10 / Linux / MAC

https://opencpn.org/wiki/dokuwiki/doku.php?id=opencpn:opencpn_user_manual:getting_started:gps_setup

Wiring details:

Red            Supply voltage ( 9v - 28v)

White         RS232 Output from GPS Antenna (NMEA0183 data on this wire)

Yellow        RS232 Input (not required - CONNECT to 0V / Ground)

Black          0v / Ground

Shield         0v / Ground

Package Contents:

1x Marine GPS Antenna Receiver 5M Cable

1x Mounting Base

** Tracked shipping used for GPS Antennas / Receivers **


** Genuine UK seller - All items ordered before 4pm **
** dispatched same day from South Derbyshire  **

NMEA 0183 4800bps RS232 protocol marine boat ship GPS

receiver antenna module DIY connector with plastic base

Model: Marine GPS Receiver

Features：

NMEA Protocol:

$GPRMC,061853.000,A,2237.5593,N,11401.5946,E,2.72,351.13,050916,,,A*6B

$GPVTG,351.13,T,,M,2.72,N,5.0,K,A*0A

$GPGGA,061853.000,2237.5593,N,11401.5946,E,1,11,0.8,106.2,M,-2.5,M,,0000*47

$GPGSA,A,3,06,17,23,02,12,05,42,50,09,19,28,,1.5,0.8,1.3*31

$GPGSV,3,1,12,02,38,308,43,05,31,225,38,06,48,003,46,09,29,082,39*7D

$GPGSV,3,2,12,12,24,311,40,17,55,095,40,19,66,053,41,23,13,056,40*78

$GPGSV,3,3,12,28,16,169,39,40,20,257,34,42,46,123,38,50,46,123,39*70

$GPGLL,2237.5593,N,11401.5946,E,061853.000,A,A*55

$xxGGA,time,lat,NS,long,EW,quality,numSV,HDOP,alt,M,sep,M,diffAge,diffStation*cs<CR><LF>

Example:

$GPGGA,061853.000,2237.5593,N,11401.5946,E,1,11,0.8,106.2,M,-2.5,M,,0000*47
